Tru-Shrink Heat Shrink Tubing, 18 to 14 AWG, Black, 6" Length, 0.3" ID Before and 0.1" ID After Shrinkage, 3:1 Shrink Ratio
(Pack of 6)

SKU:99994 Item#: 99994

Kent Automotive

Insulate and protect larger electrical wires with this heat shrink tubing. Designed to fit over thick electrical wires and ideal for applications like motor control, power distribution, and large appliance wiring. The tubing shrinks tightly around the wire to provide protection against moisture, dust, chemicals and other environmental factors that could cause damage. Manufactured for use in harsh maintenance applications where abrasion, heat, fluids and fungus are present.
• 3:1 shrink ratio
• Heat-activated adhesive liner surrounds material and produces a watertight seal
• Non-corrosive with excellent fluid and fungus resistance – non-nutrient, inert
• Meets UL Flammability Test Specification 94V2 and UL Specification 486D
• Elongation: 425%
• Minimum tensile strength: 1,542 PSI
• Minimum dielectric strength: 275V/mil
• Low-temperature flexibility: Four hours at –67°F (–55°C)
• Maximum continuous operating temperature: 194°F (90°C)
• Longitudinal change: 15% maximum, less than 5% typical
• Rated at 600V
• Designed for use in harsh maintenance applications where abrasion, heat, fluids and fungus are present
Wire gauge coverage is approximate due to the wide variance of wire thicknesses.

Check Availability

Quantity

Frequently Bought Together

Product Description

Technical Specifications

Item#:	99994
Type	Pre-Cut
Style	Heavy Wall
Wire Gauge Coverage	18-14 AWG
Length	6 "
Color	Black
I.D. Before Shrinkage	.300 "
I.D. After Shrinkage	.100 "
Shrink Ratio	3 to 1
Wall Thickness After Shrinkage	0.060 "
Voltage Rating	600 V
Temperature Rating	194 °F
Elongation	425 %
Tensile Strength	1,542 PSI
Approvals	UL, CSA
UNSPSC #:	39121723
TAA Compliant:	Yes
Weight:	0.13 lb
