Mild Steel Low Alloy High Penetration Excellent Arc Stability Polarity Dcep/Ac/Dc+/Elongation 25%
(Pack of 15)

SKU:EG10750000 Item#: EG10750000

Kent Automotive

Deep-Arc is designed perfectly for the maintenance welder. It welds through dirt, grease and other contaminants. It works at low amperage for use on low, open circuit buzz boxes. Its ability to penetrate makes it an ideal choice for poor fit-ups and root passes on thick steel.
• Welds through contaminants - little or no pre-cleaning required; including pass-over-pass without chipping slag
• Wide Amperage Range - Allows welder to control penetration
• Superior Penetration - Excellent for root and cover passes on pipe assembly or repairs
• Low Amperage - Prevents burn through on thin gauge steel and enables use on low voltage buzz boxes
• Excellent Arc Stability - Works well on inverter-type arc welders and AC machines
• Tensile strength: up to 85,000 psi/586 Mpa
• Yield strength: up to 69,000 psi/476 Mpa
• Elongation: 25%
• Machinability: Excellent
• Current: DCEP (DC+) or AC

Check Availability

Usually Ships: Today

While Supplies Last

Quantity

Frequently Bought Together

109 High Strength Electrode 5/32

Item#: EG10930000

104 Mild Steel Low Hydrogen Stick Electrode

Item#: EG1045000B

102 High Strength Steel Electrode 1/4

Item#: EG10210000

Fender Bumper Shield Retainer 11/16"

Front Bumper Drive Rivet Plastic 10mm Hole

Front Bumper Drive Rivet Plastic 7mm Hole

Cap Whip-Lead Connector #4 to #1

Oxygen Safety Cap Heavy Duty

1/2 on 1/2 Dimension I Double Pass Overlay

192047 Plasma Cutting Electrode

8-7500 Plasma Cutting Shield Cup

Oxy-Therm Striker Plate

Hinge Pin and Bushing Kit 4 Items 7Pcs

Bumper and Lower Deflector Specialty Rivet 4.8mm

Rocker and Quarter Molding Retainer Plastic

Hinge Pin and Bushing Kit 4 Items 7Pcs

Bumper and Lower Deflector Specialty Rivet 4.8mm

Rocker and Quarter Molding Retainer Plastic

Product Description

Deep-Arc is designed perfectly for the maintenance welder. It welds through dirt, grease and other contaminants. It works at low amperage for use on low, open circuit buzz boxes. Its ability to penetrate makes it an ideal choice for poor fit-ups and root passes on thick steel.
• Welds through contaminants - little or no pre-cleaning required; including pass-over-pass without chipping slag
• Wide Amperage Range - Allows welder to control penetration
• Superior Penetration - Excellent for root and cover passes on pipe assembly or repairs
• Low Amperage - Prevents burn through on thin gauge steel and enables use on low voltage buzz boxes
• Excellent Arc Stability - Works well on inverter-type arc welders and AC machines
• Tensile strength: up to 85,000 psi/586 Mpa
• Yield strength: up to 69,000 psi/476 Mpa
• Elongation: 25%
• Machinability: Excellent
• Current: DCEP (DC+) or AC

Technical Specifications

Item#:	EG10750000
Welding Process	Stick
Type	Stick
Diameter	3/32 "
Tensile Strength	85,000 PSI
Elongation	25 %
Base Metal	Mild And Medium Carbon Steel
Polarity	DCRP
UNSPSC #:	23271810
TAA Compliant:	Yes
Weight:	15.29 lb
