518C Hydraulic Hose, Urethane, 1-Steel Braided, 1/2" ID, 0.81" OD, 50' Length, 2250PSI, SAE 100R7
(Pack of
50)
SKU:95348 Item#: 95348
A solid choice for optimum kink resistance, flexibility and high voltage tolerance. Best for hydraulic circuits and systems found on utility vehicles and equipment where exposure and contact with high voltage may be encountered.
• Elastomeric core, fiber reinforcement, abrasion-resistant special PFX orange cover• 55 Series hose ends
SAE 100R7
• Temperature range: –40°F to +250°F (–40°C to +121°C)• Limited to 135°F (57°C) for synthetic hydraulic and water-based fluids• Meets SAE J517 for less than 50 micro-amps leakage under 75,000V per foot• Meets or exceeds Ontario Hydro electrical standards• Complies with ANSI A92.2 for vehicle-mounted aerial devices
Frequently Bought Together
3TR7 Hydraulic Thermoplastic Hose 0.43" x 50'
$0.00
Couldn't load pickup availability
3TR8N Hydraulic Thermoplastic Hose 0.75" x 50'
$0.00
Couldn't load pickup availability
3TR8 Hydraulic Thermoplastic Hose 0.75" x 50'
$0.00
Couldn't load pickup availability
Industrial O-Ring Nitrile 1/8 x 1/4 x 1/16"
$0.00
Couldn't load pickup availability
Spacer Ring Black
$0.00
Couldn't load pickup availability
Air Conditioning O-Ring HSN 0.617 x 0.769"
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 3/4 to 1-3/4"
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose assembly w/ Industrial safety coupler
$0.00
Couldn't load pickup availability
Quick Disconnect Coupler Brass 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
Specialty Rivet with Plastic Cap Aluminum 3.2mm
$0.00
Couldn't load pickup availability
Inner Fender Shield Attaching Clip Nylon Black
$0.00
Couldn't load pickup availability
Front Fender Liner Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.82" x 50'
$0.00
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.49" x 50'
$0.00
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.65" x 50'
$0.00
Couldn't load pickup availability
Product Description
A solid choice for optimum kink resistance, flexibility and high voltage tolerance. Best for hydraulic circuits and systems found on utility vehicles and equipment where exposure and contact with high voltage may be encountered.• Elastomeric core, fiber reinforcement, abrasion-resistant special PFX orange cover• 55 Series hose ends
SAE 100R7
• Temperature range: –40°F to +250°F (–40°C to +121°C)• Limited to 135°F (57°C) for synthetic hydraulic and water-based fluids• Meets SAE J517 for less than 50 micro-amps leakage under 75,000V per foot• Meets or exceeds Ontario Hydro electrical standards• Complies with ANSI A92.2 for vehicle-mounted aerial devices
Technical Specifications
| Item#: | 95348 |
|---|---|
| Manufacturer Model #: | 518C |
| Type | Thermoplastic Hose |
| Category / Performance | Medium Pressure - Non-Conductive |
| Industry Rating 1 | SAE 100R7 NC |
| Industry Rating 2 | ANSI A92.2 |
| Manufacturer Series Number | 518C |
| Manufacturer Series Name | Parflex |
| Dash Size | -8 |
| Working Pressure | 2,250 PSI |
| Burst Pressure | 9,000 PSI |
| Minimum Bend Radius | 3 " |
| Inner Tube Material | Polyester |
| Hose Reinforcement | Fiber |
| Hose Cover Material | Non-perforated Proprietary Blend PFX |
| Fitting Series | 51 |
| Temperature | -40F to +212F |
| Color | Orange |
| Size | 1/2 (-8) |
| Parker Field Attaching Fittings | 51 |
| Swage Die Selection | 88806 |
| UNSPSC #: | 40142020 |
| TAA Compliant: | Yes |
| Weight: | 9.0 lb |
Product Restrictions
