Flexible Battery Cable, 3/0 AWG, Total Strands 1596, 25' Length, Red, 600 Volts, Purple-Crimp Color Code, Copper Conductor
(Pack of
1)
SKU:P52742 Item#: P52742
• Contains up to three times the strand count of regular battery cables
• Extra high count, rope-stranded, electrolytic copper conductors ensure maximum conductivity and cool operation
• Unique extruded inner yellow sleeve lies between conductors and outer jacket to provide an extra margin of protection against corrosion and cut-through
• Premium thermoplastic rubber insulation jacket provides the best overall chemical, heat, cold and flame resistance; highly resistant to UV light and ozone exposure; remains flexible over a long service life
•Temperature range: –56.2°F to +221°F (–49°C to +105°C)
• 600V maximum
• SAE J378C / J1127
• Marine rated
• A superior, high-performance battery cable for automotive and marine applications, as well as industrial and institutional battery backup power systems
Frequently Bought Together
Battery Cable Spacer for Extra-Long Battery Bolt
$0.00
Couldn't load pickup availability
Flexible Battery Cable 4/0 AWG Black 25'
$0.00
Couldn't load pickup availability
Flexible Battery Cable 2/0 AWG Red 25'
$0.00
Couldn't load pickup availability
Nylon Cable Tie 11-3/4" Black
$0.00
Couldn't load pickup availability
Miniature Incandescent Bulb 12V 3CP
$0.00
Couldn't load pickup availability
Nylon Cable Tie 7-1/2" Black
$0.00
Couldn't load pickup availability
Heavy-Duty Battery Cable Lug 1/0 AWG Pink 3/8"
$0.00
Couldn't load pickup availability
Heavy-Duty Battery Cable Lug 4 AWG Gray 5/16"
$0.00
Couldn't load pickup availability
Socket Terminal Contact 16-14 AWG
$0.00
Couldn't load pickup availability
Fender Apron Drive Rivet 8mm Hole
$0.00
Couldn't load pickup availability
Engine Under Cover Drive Rivet Plastic 7mm Hole
$0.00
Couldn't load pickup availability
Cowl Bumper Fender Liner/Engine Under Cover Rivet
$0.00
Couldn't load pickup availability
Product Description
• Contains up to three times the strand count of regular battery cables• Extra high count, rope-stranded, electrolytic copper conductors ensure maximum conductivity and cool operation
• Unique extruded inner yellow sleeve lies between conductors and outer jacket to provide an extra margin of protection against corrosion and cut-through
• Premium thermoplastic rubber insulation jacket provides the best overall chemical, heat, cold and flame resistance; highly resistant to UV light and ozone exposure; remains flexible over a long service life
•Temperature range: –56.2°F to +221°F (–49°C to +105°C)
• 600V maximum
• SAE J378C / J1127
• Marine rated
• A superior, high-performance battery cable for automotive and marine applications, as well as industrial and institutional battery backup power systems
Technical Specifications
| Item#: | P52742 |
|---|---|
| Cable Gauge | 3/0 |
| Total Strands | 1,596 |
| Color | Red |
| Volts | 600 V |
| Minimum Temperature Rating | -40 °F |
| Maximum Temperature Rating | 221 °F |
| Length | 25 ft |
| Crimp Color Code | Purple |
| Amperage Capacity at 140°F (60°C) | 260 A |
| Amperage Capacity at 167°F (75°C) | 310 A |
| Amperage Capacity at 194°F (90°C) | 350 A |
| Specifications | SAE J378C/J1127, UL 62-SJE,SE,SEO |
| Style | Premium Flexible |
| Type | Battery Cable |
| UNSPSC #: | 39121405 |
| TAA Compliant: | Yes |
| Weight: | 18.45 lb |
Product Restrictions
