Home Bolts Hex Cap Screw Grade 8 3/8-16 x 3"
Bolts

Hex Cap Screw, Grade 8, Alloy Steel, Yellow Zinc Finish, Coarse Thread, 15/64" Head Height, 9/16" Across Flats, 3/8-16 x 3"
(Pack of 50)

Item#: FA68040

FalconGrip®

• 150,000 PSI minimum tensile strength (SAE Grade 8)
• Conforms to SAE J429 material and mechanical properties
• Available in coarse (UNC) and fine (UNF) thread types
• Product dimensions to ANSI B18.2.1

Read More
Check Availability

Catalog page#: 11-14

Frequently Bought Together


DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 40mm

Item#: 59416

Hex Cap Screw Grade 10.9 Alloy Steel M6-1 x 12mm

Item#: 10203

Hex Cap Screw Property Class 8.8 M10-1.5 x 35mm

Item#: 61271

Hex Cap Screw Property Class 8.8 M6-1 x 40mm

Item#: 27335

Hex Cap Screw Property Class 10.9 M8-1.25 x 35mm

Item#: 4285

Hex Cap Screw Grade 8 5/16-18 x 1"

Item#: FA68017

Hex Flange Nut Grade 8 Steel M8-1.25

Item#: 57129

Hex Flange Bolt Grade 10.9 M10-1.25 x 20mm

Item#: 55607

Hex Flange Bolt Grade 10.9 M10-1.25 x 40mm

Item#: 55609

Hex Flange Nut Grade 8 Steel M6-1

Item#: 57128

Hex Cap Screw Property Class 8.8 M10-1.5 x 30mm

Item#: 61270

DIN 6921 Hex Flange Bolt Grade 8.8 M6-1 x 20mm

Item#: 59408

Molding Clip with Sealer Nylon White 10 x 12mm

Item#: P85218

Rocker Door and Exterior Molding Retainer

Item#: 1446663

Phillips Truss Head Sheet Metal Screw Steel 15mm

Item#: P13770

Product Description

• 150,000 PSI minimum tensile strength (SAE Grade 8)
• Conforms to SAE J429 material and mechanical properties
• Available in coarse (UNC) and fine (UNF) thread types
• Product dimensions to ANSI B18.2.1

Technical Specifications

Item#: FA68040
Style Industry Standard
Diameter 3/8 "
Thread Pitch 16
Thread Coarse
Length 3 "
Type Hex Cap Screw
Across Flats 9/16 "
Material Alloy Steel
Grade 8
Finish Yellow Zinc
Tensile Strength 150,000 PSI
Specifications SAE J429
Head Style Hex
Head Height 15/64 "
Thread Form UNR
Thread Length Partial
Thread Length Minimum 1 "
UNSPSC #: 31161501
TAA Compliant: No
Weight: 5.08 lb
