Kurt Tuff Xtra-Flex, High Pressure Hydraulic Hose, Very High Pressure, Light Weight, One Million Impulse Cycle Hose
(Pack of
400)
SKU:1692935 Item#: 1692935
KURT Tuff high-pressure hydraulic hose was designed and engineered by KURT Hydraulics’ in-house development team. It is a truly unique product unlike anything else on the market today. KURT Tuff’s superior performance and quality give us a distinct competitive advantage in the high-pressure hydraulic hose industry. With a high-pressure hydraulic hose from KURT Hydraulics, you can expect a usable life that is up to four times as long as standard hoses, tested and proven through 1 million impulse cycles.
• Fittings Certified:
– W Series(-4 through -16)
– STD/KH Series (-4 through -16)
– K2 Series (-4 through -8)
• Agency Approval: MSHA
• Construction:
– Inner Tube: Oil resistant synthetic rubber
– Reinforcement: Two high tensile steel wire braid
– Cover: 10X abrasion, ozone and weather resistant synthetic rubber
• Operating Temperature Range: –40°F to +212°F (-40°C to +100°C)
Frequently Bought Together
3TR7 Hydraulic Thermoplastic Hose 0.65" x 50'
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.57" x 250'
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.43" x 500'
Couldn't load pickup availability
06Z-BC68- Hose End (perm) 1S/1R 90 D Male STC
Couldn't load pickup availability
08Z-BC68- Hose End (perm) 1S/1R 90 D Male STC
Couldn't load pickup availability
06Z-BC46- Hose End (perm) 1S/1R 45 D Male STC
Couldn't load pickup availability
Hose Clamp 301 SS 9/16 to 1-1/16"
Couldn't load pickup availability
Worm Gear Hose Clamp Assortment with Rack
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 25' air hose
Couldn't load pickup availability
Avagard PVC Water Hose Assembly 5/8" x 50'
Couldn't load pickup availability
Avagard PVC Water Hose Assembly 3/4" x 100'
Couldn't load pickup availability
AG-Lite Rubber Water Hose Lead In 1" x 6'
Couldn't load pickup availability
Shield Push-Type Retainer with Metal Insert
Couldn't load pickup availability
Front Bumper Trim Panel/Running Board Split Rivet
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Product Description
KURT Tuff high-pressure hydraulic hose was designed and engineered by KURT Hydraulics’ in-house development team. It is a truly unique product unlike anything else on the market today. KURT Tuff’s superior performance and quality give us a distinct competitive advantage in the high-pressure hydraulic hose industry. With a high-pressure hydraulic hose from KURT Hydraulics, you can expect a usable life that is up to four times as long as standard hoses, tested and proven through 1 million impulse cycles.• Fittings Certified:
– W Series(-4 through -16)
– STD/KH Series (-4 through -16)
– K2 Series (-4 through -8)
• Agency Approval: MSHA
• Construction:
– Inner Tube: Oil resistant synthetic rubber
– Reinforcement: Two high tensile steel wire braid
– Cover: 10X abrasion, ozone and weather resistant synthetic rubber
• Operating Temperature Range: –40°F to +212°F (-40°C to +100°C)
Technical Specifications
| Item#: | 1692935 |
|---|---|
| Industrial / Hydraulic | Hydraulic |
| Type | Rubber - Steel Braided |
| Category / Performance | High Pressure |
| Manufacturer Series Name | Kurt TUFF |
| I.D. | 3/8 (-6) " |
| Hose O.D. | 0.67 " |
| Working Pressure | 5,585 PSI |
| Burst Pressure | 22,340 PSI |
| Fitting Series | STD/KH, W, K2 |
| Bend Radius | 3.00 " |
| Inner Tube Material | Oil resistant synthetic rubber |
| Hose Reinforcement | Two high tensile steel wire braid |
| Hose Cover Material | 10x abrasion, ozone and weather resistant synthetic rubber |
| Temperature | -40° to +212°F |
| Dash Size | -6 |
| Applications | Agriculture, Construction, Industrial, Logging, Marine, Mining, Mobile Equipment, Oil & Gas |
| UNSPSC #: | 40142020 |
| TAA Compliant: | No |
