Kurt Tuff Xtra-Flex, High Pressure Hydraulic Hose, Very High Pressure, Light Weight, One Million Impulse Cycle Hose
(Pack of
400)
SKU:1692935 Item#: 1692935
KURT Tuff high-pressure hydraulic hose was designed and engineered by KURT Hydraulics’ in-house development team. It is a truly unique product unlike anything else on the market today. KURT Tuff’s superior performance and quality give us a distinct competitive advantage in the high-pressure hydraulic hose industry. With a high-pressure hydraulic hose from KURT Hydraulics, you can expect a usable life that is up to four times as long as standard hoses, tested and proven through 1 million impulse cycles.
• Fittings Certified:
– W Series(-4 through -16)
– STD/KH Series (-4 through -16)
– K2 Series (-4 through -8)
• Agency Approval: MSHA
• Construction:
– Inner Tube: Oil resistant synthetic rubber
– Reinforcement: Two high tensile steel wire braid
– Cover: 10X abrasion, ozone and weather resistant synthetic rubber
• Operating Temperature Range: –40°F to +212°F (-40°C to +100°C)
Frequently Bought Together
Kurt Tuff Xtra-Flex High Pressure Hydraulic Hose, 200 Foot
$0.00
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.43" x 50'
$0.00
Couldn't load pickup availability
3TR8N Hydraulic Thermoplastic Hose 0.75" x 50'
$0.00
Couldn't load pickup availability
Industrial O-Ring Nitrile 7/32 x 11/32 x 1/16"
$0.00
Couldn't load pickup availability
Industrial O-Ring Nitrile 1/8 x 1/4 x 1/16"
$0.00
Couldn't load pickup availability
Spacer Ring Black
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose assembly w/ Industrial safety coupler
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 9/16 to 1-1/4"
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose
$0.00
Couldn't load pickup availability
Kurt Tuff Xtra-Flex High Pressure Hydraulic Hose, 200 Foot
$0.00
Couldn't load pickup availability
Kurt Tuff Xtra-Flex High Pressure Hydraulic Hose, 300 Foot
$0.00
Couldn't load pickup availability
Kurt Tuff Xtra-Flex High Pressure Hydraulic Hose, 200 Foot
$0.00
Couldn't load pickup availability
Specialty Rivet with Plastic Cap Aluminum 3.2mm
$0.00
Couldn't load pickup availability
Fender Splash Shield Push Rivet Nylon 7mm Hole
$0.00
Couldn't load pickup availability
Inner Fender Shield Attaching Clip Nylon Black
$0.00
Couldn't load pickup availability
Product Description
KURT Tuff high-pressure hydraulic hose was designed and engineered by KURT Hydraulics’ in-house development team. It is a truly unique product unlike anything else on the market today. KURT Tuff’s superior performance and quality give us a distinct competitive advantage in the high-pressure hydraulic hose industry. With a high-pressure hydraulic hose from KURT Hydraulics, you can expect a usable life that is up to four times as long as standard hoses, tested and proven through 1 million impulse cycles.• Fittings Certified:
– W Series(-4 through -16)
– STD/KH Series (-4 through -16)
– K2 Series (-4 through -8)
• Agency Approval: MSHA
• Construction:
– Inner Tube: Oil resistant synthetic rubber
– Reinforcement: Two high tensile steel wire braid
– Cover: 10X abrasion, ozone and weather resistant synthetic rubber
• Operating Temperature Range: –40°F to +212°F (-40°C to +100°C)
Technical Specifications
| Item#: | 1692935 |
|---|---|
| Manufacturer Model #: | KT-06-REEL |
| Industrial / Hydraulic | Hydraulic |
| Type | Rubber - Steel Braided |
| Category / Performance | High Pressure |
| Manufacturer Series Name | Kurt TUFF |
| I.D. | 3/8 (-6) " |
| Hose O.D. | 0.67 " |
| Working Pressure | 5,585 PSI |
| Burst Pressure | 22,340 PSI |
| Fitting Series | STD/KH, W, K2 |
| Bend Radius | 3.00 " |
| Inner Tube Material | Oil resistant synthetic rubber |
| Hose Reinforcement | Two high tensile steel wire braid |
| Hose Cover Material | 10x abrasion, ozone and weather resistant synthetic rubber |
| Temperature | -40° to +212°F |
| Dash Size | -6 |
| Applications | Agriculture, Construction, Industrial, Logging, Marine, Mining, Mobile Equipment, Oil & Gas |
| UNSPSC #: | 40142020 |
| TAA Compliant: | No |
