Open End Rivet, Dome Head, Aluminum, 3/16" Diameter, 0.251 to 0.375" Grip Range, 0.575" Body Length
(Pack of
100)
SKU:489 Item#: 489
Dome Head
• Head diameter is twice the body diameter, providing adequate bearing for nearly all applications
Couldn't load pickup availability
Catalog page#: 11-106
Frequently Bought Together
Blind Rivet Nut Insert Thin Wall M6-1
Couldn't load pickup availability
Hex Cap Screw Property Class 8.8 M10-1.5 x 40mm
Couldn't load pickup availability
DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 16mm
Couldn't load pickup availability
Open End Rivet Large Flange Head SS 1/8"
Couldn't load pickup availability
Open End Rivet Large Flange Head SS 1/8"
Couldn't load pickup availability
Open End Rivet Dome Head Stainless Steel 1/8"
Couldn't load pickup availability
Open End Rivet Large Flange Head Aluminum 1/8"
Couldn't load pickup availability
Structural Rivet Internal Lock Steel 1/4"
Couldn't load pickup availability
Open End Rivet Dome Head Aluminum 1/8"
Couldn't load pickup availability
Fender Liner Screw Grommet Nylon M5.5
Couldn't load pickup availability
Nylon Cable Tie 15-1/4" Black
Couldn't load pickup availability
Phillips Truss Head Sheet Metal Screw Steel 15mm
Couldn't load pickup availability
Product Description
Dome Head• Head diameter is twice the body diameter, providing adequate bearing for nearly all applications
Technical Specifications
| Item#: | 489 |
|---|---|
| Type | Open End |
| Head Style | Dome Head |
| Material Body / Mandrel | Aluminum/Aluminum |
| Diameter | 3/16 " |
| Grip Range | 0.251 – 0.375 " |
| Industry Number | 66 |
| Hole Size | 0.192 – 0.196 " |
| Drill Size | #11 |
| Head Diameter | 0.375 " |
| Head Height | 0.060 " |
| Body Length | 0.575 " |
| Shear Strength | 260 lb |
| Tensile Strength | 320 lb |
| Kent Complete 2 Location | Drawer N : Row 3 : Column 2 |
| UNSPSC #: | 31162201 |
| TAA Compliant: | No |
| Weight: | 0.33 lb |
