Push-Button Coupler Plug, Steel, High Flow, 175PSI Maximum Working Pressure, Male NPTF, 1/4" Body Size, 3/8-18 Thread Size
(Pack of
1)
• Specially engineered to allow almost twice the air flow of comparably sized couplers
• Do not qualify as safety couplers
• Body color: Blue with green button – outside plastic covering indicates if it is a regular coupler (blue or gray) or a safety coupler (black)
• Simple – just push button to release
• Button is recessed to prevent accidental disconnect
• Extremely durable – constructed of steel components encased in a high-impact, non-marring body
• Manufactured to demanding ANSI and ISO standards
• Temperature range: 5°F to 160°F (–15°C to +71°C)
• Maximum working pressure: 175 PSI
• Ideal for HVLP (High Volume/Low Pressure) applications such as paint guns
Frequently Bought Together
Quick Disconnect Coupler Steel 1/2" x 1/2-14
Couldn't load pickup availability
Quick Disconnect Coupler Steel 1/2 x 1/2"
Couldn't load pickup availability
Nipple, Industrial, 1/4'' Body, 1/4-18 Male NPTF, 303 SS
Couldn't load pickup availability
Sheet Metal Drill Bit Alloy Steel 1/4"
Couldn't load pickup availability
Spot Weld Remover Drill Bit HSS 2-13/16(M8)
Couldn't load pickup availability
Spot Weld Remover Drill Bit Cobalt 5/16" (M8)
Couldn't load pickup availability
Serrated Hex Flange Nut Alloy Steel M10-1.25
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M6-1 x 16mm
Couldn't load pickup availability
Rusty™ 3000 Brake Plate/High Temperature Lubricant
Couldn't load pickup availability
Hose Barb Brass 1/2" x 1/4-18
Couldn't load pickup availability
Hose Barb Brass 5/16" x 1/4-18
Couldn't load pickup availability
Combination Nipple Steel 3/4-14 x 3/4"
Couldn't load pickup availability
Pipe Close Nipple Brass 1/4-18 x 1/4-18
Couldn't load pickup availability
Pipe Bushing Brass 3/8-18 x 1/4-18
Couldn't load pickup availability
Pipe Adapter Brass 1/4-18 x 1/4-18
Couldn't load pickup availability
Barb-Lok Hose End 3/8" (-6) x 1/4-18 (-4)
Couldn't load pickup availability
Barb-Tite™ Instrumentation Elbow 3/8 x 1/4"
Couldn't load pickup availability
Barb-Lok Hose End 1/4" (-4) x 5/8-18 (-6)
Couldn't load pickup availability
Hex Head Sheet Metal Screw with 16mm Washer Steel
Couldn't load pickup availability
Bumper Drive Rivet Plastic 10mm Hole
Couldn't load pickup availability
Bumper Cover Push-Type Retainer Nylon 18mm
Couldn't load pickup availability
Product Description
• Specially engineered to allow almost twice the air flow of comparably sized couplers• Do not qualify as safety couplers
• Body color: Blue with green button – outside plastic covering indicates if it is a regular coupler (blue or gray) or a safety coupler (black)
• Simple – just push button to release
• Button is recessed to prevent accidental disconnect
• Extremely durable – constructed of steel components encased in a high-impact, non-marring body
• Manufactured to demanding ANSI and ISO standards
• Temperature range: 5°F to 160°F (–15°C to +71°C)
• Maximum working pressure: 175 PSI
• Ideal for HVLP (High Volume/Low Pressure) applications such as paint guns
Technical Specifications
| Item#: | KT15130 |
|---|---|
| Description | Push-Button Coupler |
| Type | Nipple |
| Style | High Flow |
| Body Size | 1/4 " |
| Thread Style | Male NPTF |
| Thread Size | 3/8-18 |
| Material | Steel |
| UNSPSC #: | 27131613 |
| TAA Compliant: | Yes |
| Weight: | 0.07 lb |
