Ring Tongue Terminal 16 to 14 AWG Blue
(Pack of
100.0)
Visa Crimp™ provides a high-quality crimp terminal connection. The brazed-seam barrel single crimp design will not open from wire pull, vibration or stress, providing a reliable connection.
Visa Crimp™ terminals feature:
• Brazed seam barrel
• Funnel-mouth barrel entry for easy wire insertion
• Long barrel for easier crimping in any position
• Translucent insulation for foolproof crimping; crack- and chemical-resistance
Visa Crimp™
• Same as the ring tongue with the added benefit of accepting multiple stud sizes – stock one terminal for three different stud sizes
• Manufactured from high-grade copper for the highest conductivity
• Annealed to flow freely under crimping pressure for best connection
• Electro-tin-plated for greatest corrosion resistance
• Meets MIL-T-10727 Specifications
• Maximum voltage rating: 600V at 221°F (105°C); 1,000V in signs, fixtures and luminaries
• Amperage ratings: 26–24 Ga. 3A; 22–18 Ga. 7A; 16–14 Ga. 15A; 12–10 Ga. 30A
• Operating temperature: –40°F to +221°F (–40°C to +105°C)
For extreme duty
• Reduce inventory – stock one terminal for three different stud sizes
• Usable with solid and stranded wire
• V-groove serrations act as a lock washer to hold the terminal in place and to resist vibration and connection failure
• Electrolytic copper composition (Federal Specification QQC576) provides high conductivity and allows connections to run cooler
• Visa Crimp™ insulation will not support combustion
Frequently Bought Together
Universal Plug-In Circuit Breaker Type I 10A
Couldn't load pickup availability
Lithium Battery #2450 3V
Couldn't load pickup availability
ATO/ATC Fuse 15A Light Blue
Couldn't load pickup availability
Ring Tongue Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Ring Tongue Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Autobahn Ergo Magna EZ Crimper Ratcheting Terminal Crimper
Couldn't load pickup availability
Miniature Incandescent Bulb 12V 2CP
Couldn't load pickup availability
Fork Pigtail Connector 12 AWG White
Couldn't load pickup availability
Watertight Wire Nuts 3 X 22 or 4 X 12 or 3 X 10 Gauge Light Blue
Couldn't load pickup availability
Product Description
Visa Crimp™ provides a high-quality crimp terminal connection. The brazed-seam barrel single crimp design will not open from wire pull, vibration or stress, providing a reliable connection.Visa Crimp™ terminals feature:
• Brazed seam barrel
• Funnel-mouth barrel entry for easy wire insertion
• Long barrel for easier crimping in any position
• Translucent insulation for foolproof crimping; crack- and chemical-resistance
Visa Crimp™
• Same as the ring tongue with the added benefit of accepting multiple stud sizes – stock one terminal for three different stud sizes
• Manufactured from high-grade copper for the highest conductivity
• Annealed to flow freely under crimping pressure for best connection
• Electro-tin-plated for greatest corrosion resistance
• Meets MIL-T-10727 Specifications
• Maximum voltage rating: 600V at 221°F (105°C); 1,000V in signs, fixtures and luminaries
• Amperage ratings: 26–24 Ga. 3A; 22–18 Ga. 7A; 16–14 Ga. 15A; 12–10 Ga. 30A
• Operating temperature: –40°F to +221°F (–40°C to +105°C)
For extreme duty
• Reduce inventory – stock one terminal for three different stud sizes
• Usable with solid and stranded wire
• V-groove serrations act as a lock washer to hold the terminal in place and to resist vibration and connection failure
• Electrolytic copper composition (Federal Specification QQC576) provides high conductivity and allows connections to run cooler
• Visa Crimp™ insulation will not support combustion
Technical Specifications
| Item#: | P38783 |
|---|---|
| Type | Crimp |
| Wire Gauge | 16-14 AWG |
| Stud Size | 6-8-10 |
| Color | Blue |
| Approvals | UL, CSA |
| UNSPSC #: | 39121432 |
| TAA Compliant: | Yes |
| Weight: | 0.26 lb |
