SNAPTOGGLE® Toggle Bolt Anchor, 3/4" Drill Size, 3/8-16
(Pack of
10)
SKU:90919 Item#: 90919
• Three times faster than conventional toggle bolts
• Requires a smaller pilot hole and uses a shorter bolt
• Stays in place with or without a bolt
• Heads won’t fall behind wall
• Wall or ceiling thickness range: 3/8" – 2-1/2"
• Minimum bolt length: Fixture thickness + wall or ceiling thickness + 1/2"
• Minimum clearance behind wall: 1-7/8"
Tests are ultimate load. However, industry safety standards recommend 1/4 of the value for actual application. Age and condition of the material and the screw size will cause tensile strength to vary.Toggler® is a registered trademark of Mechanical Plastics Corp.
Frequently Bought Together
Masonry Anchor Assortment 700Pcs
$0.00
Couldn't load pickup availability
Conical Screw Anchor Kit Plastic 101Pcs
$0.00
Couldn't load pickup availability
E-Z Anchor Kit Steel 41Pcs
$0.00
Couldn't load pickup availability
Open End Rivet Large Flange Head Aluminum 3/16"
$0.00
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M8-1.25 x 25mm
$0.00
Couldn't load pickup availability
Open End Rivet Dome Head Aluminum 5/32"
$0.00
Couldn't load pickup availability
Specialty Rivet with Plastic Cap Aluminum 3.2mm
$0.00
Couldn't load pickup availability
Inner Fender Shield Attaching Clip Nylon Black
$0.00
Couldn't load pickup availability
Front Fender Liner Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Hollow Wall Screw Anchor Steel Long Style 1/8"
$0.00
Couldn't load pickup availability
Tamper-Proof Nail Drive Anchor Steel 1/4 x 3/4"
$0.00
Couldn't load pickup availability
Hollow Wall Screw Anchor Steel Short Style #6-32
$0.00
Couldn't load pickup availability
Product Description
• Three times faster than conventional toggle bolts• Requires a smaller pilot hole and uses a shorter bolt
• Stays in place with or without a bolt
• Heads won’t fall behind wall
• Wall or ceiling thickness range: 3/8" – 2-1/2"
• Minimum bolt length: Fixture thickness + wall or ceiling thickness + 1/2"
• Minimum clearance behind wall: 1-7/8"
Tests are ultimate load. However, industry safety standards recommend 1/4 of the value for actual application. Age and condition of the material and the screw size will cause tensile strength to vary.Toggler® is a registered trademark of Mechanical Plastics Corp.
Technical Specifications
| Item#: | 90919 |
|---|---|
| Type | Toggle Bolt Anchor |
| Size | 3/8-16 " |
| Diameter | 3/8 " |
| Thread | Coarse |
| Thread Pitch | 16 tpi |
| Drill Size | 3/4 " |
| Tensile Proof Test Load In Concrete | 1,167 lb |
| Shear Proof Test Load | 2,044 lb |
| Tensile Proof Test Load | 1120 lb |
| Bolt Size | 3/8-16 " |
| UNSPSC #: | 31162103 |
| TAA Compliant: | Yes |
| Weight: | 0.68 lb |
