H039 Weatherhead Suction/Return Line Hose, CPE Inner Tube, Neoprene Steel Helix, Black, 200PSI, 1-1/4" (-20) ID
(Pack of
50)
SKU:64628 20 Item#: 64628 20
• Agency Ratings: SAE 100R4AT
• Fittings Certified: Z-Series
• Agency Approvals: MSHA, Marine Application J1942/1 Hydraulic Service, ABS
• Construction:
– Inner Tube: CPE
– Reinforcement: One helical cable wire between two textile layers plus one fabric braid
– Cover: Neoprene
• Temperature Range:
– Petroleum-based fluids: –40°F to +275°F (–40°C to +135°C)
• Application Note: Hydraulic suction hose
Consists of no more than two pieces totaling 50 feet (±10%)
Frequently Bought Together
Royalflex Suction and Discharge Hose 2" Blue
$0.00
Couldn't load pickup availability
Mill Suction and Discharge Hose 2-1/2" White
$0.00
Couldn't load pickup availability
Layflat PVC Discharge Hose Assembly 3" x 50' Blue
$0.00
Couldn't load pickup availability
Air Master® Diving Umbilical 1/2" ID X 300' Length, Black
$0.00
Couldn't load pickup availability
Air Master® Diving Umbilical 1/2" ID X 50' Length, Black
$0.00
Couldn't load pickup availability
Air Master® Diving Umbilical 1/2" ID X 1,000' Length, Black
$0.00
Couldn't load pickup availability
DOT Connector Male Brass 5/8 x 1/2-14
$0.00
Couldn't load pickup availability
DOT Swivel Elbow Male 360° Brass 3/8 x 1/4-18
$0.00
Couldn't load pickup availability
Standard Industrial Safety Push-Button Safety Coupler 1/4" Body x 1/4" FNPT
$0.00
Couldn't load pickup availability
Rocker Door and Exterior Molding Retainer
$0.00
Couldn't load pickup availability
Front Bumper Push-Type Retainer Nylon 10mm
$0.00
Couldn't load pickup availability
Phillips Truss Head Sheet Metal Screw Steel 15mm
$0.00
Couldn't load pickup availability
Product Description
• Agency Ratings: SAE 100R4AT• Fittings Certified: Z-Series
• Agency Approvals: MSHA, Marine Application J1942/1 Hydraulic Service, ABS
• Construction:
– Inner Tube: CPE
– Reinforcement: One helical cable wire between two textile layers plus one fabric braid
– Cover: Neoprene
• Temperature Range:
– Petroleum-based fluids: –40°F to +275°F (–40°C to +135°C)
• Application Note: Hydraulic suction hose
Consists of no more than two pieces totaling 50 feet (±10%)
Technical Specifications
| Item#: | 64628 20 |
|---|---|
| Type | Suction and Discharge |
| Industry Rating 1 | SAE 100R4 |
| Manufacturer Series Number | H039 |
| Manufacturer Series Name | Weatherhead |
| I.D. | 1-1/4 (-20) " |
| Working Pressure | 200 PSI |
| Minimum Bend Radius | 4 " |
| Inner Tube Material | CPE |
| Hose Cover Material | Neoprene |
| Fitting Series | Z-Series |
| Temperature | -40F to +275F |
| Color | Black |
| Size | 1-1/4 (-20) |
| Mercury Vacuum (Inches) | 25 |
| UNSPSC #: | 40142000 |
| TAA Compliant: | Yes |
| Weight: | 37.0 lb |
