Wire Rope Terminal, Single Shank Ball, 1/16", Stainless Steel
(Pack of
5)
SKU:1440353 Item#: 1440353
Single Shank Ball end fittings will exceed the minimum breaking strength of the cable on to which it is swaged.
• Stainless Steel
• Meets MIL-DTL-781
Frequently Bought Together
Wire Rope Terminal, Single Shank Ball, 1/8", Stainless Steel
Item#: 1440272
$0.00
Couldn't load pickup availability
Wire Rope Terminal, Plain Ball, 3/16", Stainless Steel
Item#: 1440287
$0.00
Couldn't load pickup availability
Wire Rope Terminal, Plain Ball, 3/32", Stainless Steel
Item#: 1440396
$0.00
Couldn't load pickup availability
Wire Rope Terminal, Eye End, 1/8", Stainless Steel
Item#: 1440301
$0.00
Couldn't load pickup availability
Wire Rope Terminal, Plain Ball, 3/32", Stainless Steel
Item#: 1440396
$0.00
Couldn't load pickup availability
Wire Rope Terminal, Eye End, 3/16", Stainless Steel
Item#: 1440231
$0.00
Couldn't load pickup availability
20' Aluminum Plank & Stages
Item#: 1329266
$0.00
Couldn't load pickup availability
Wire Rope Uncoated 3200 Lb Safe Load 7/16" x 100'
Item#: 64287
$0.00
Couldn't load pickup availability
ShelfMaxâ„¢ Bin, Blue, 17-5/8" x 8/3/8" x 6"
Item#: 1387963
$0.00
Couldn't load pickup availability
Front Bumper Push-Type Retainer Nylon 20mm
Item#: P15599
$0.00
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
Item#: KT11580
$0.00
Couldn't load pickup availability
Front Bumper and Radiator Support Drive Rivet
Item#: KT13537
$0.00
Couldn't load pickup availability
Wire Rope Sleeve, 7/16", Copper, Zinc Plated
Item#: 1440285
$0.00
Couldn't load pickup availability
Wire Rope Thimble, 3/8", Steel, Galvanized, Heavy-Duty
Item#: 1442357
$0.00
Couldn't load pickup availability
Wire Rope Terminal, Marine Eye End, 3/16", Stainless Steel
Item#: 1440207
$0.00
Couldn't load pickup availability
Product Description
Single Shank Ball end fittings will exceed the minimum breaking strength of the cable on to which it is swaged.• Stainless Steel
• Meets MIL-DTL-781
Technical Specifications
| Item#: | 1440353 |
|---|---|
| Manufacturer Model #: | MS20664C2 |
| Type | Single Shank Ball |
| Cable Diameter | 1/16 " |
| Material | Stainless Steel |
| A | 0.132 " |
| As | 0.112 " |
| B | 0.212 " |
| Bs | 0.190 " |
| Cs | 0.156 " |
| D | 0.114 " |
| E | 0.0825 " |
| L | 0.2685 " |
| N | 0.073 " |
| Rs | 0.014 " |
| UNSPSC #: | 31162812 |
| TAA Compliant: | Yes |
| Weight: | 0.015 lb |
