Turnbuckle, Eye and Eye, Galvanized, 7/8" x 12"
(Pack of
1)
• Turnbuckles can be used to apply tension to wire rope or cable
• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class D
• Apply load to the center of end attachment eyes – do not side load eyes
CAUTION: Do not exceed working load limits.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
Eyebolt, With Nut, Galvanized, 1/2" x 4-1/2"
Couldn't load pickup availability
Turned Eyebolt, Zinc-Plated, 5/16" x 3"
Couldn't load pickup availability
Eyebolt, Machinery, Stainless Steel, 5/16" x 1-1/8"
Couldn't load pickup availability
Wire Rope, Steel, Bare, 7x7, 3/32", 920 lbs Breaking Strength
Couldn't load pickup availability
Wire Rope, Steel, Vinyl Coated, 7x19, 1/4", 7,000 lbs Breaking Strengt
Couldn't load pickup availability
Wire Rope, Steel, Nylon Coated, 7x19, 3/16", 4,200 lbs Breaking Streng
Couldn't load pickup availability
Fender Bumper Shield Retainer 11/16"
Couldn't load pickup availability
Specialty Rivet with Plastic Cap Aluminum 3.2mm
Couldn't load pickup availability
Drive Rivet Nylon M8
Couldn't load pickup availability
Turnbuckle, Stainless Steel, Jaw and Jaw, 5/16" x 4.00" Take Up
Couldn't load pickup availability
Turnbuckle, Stainless Steel, Full Thread, 1/2" x 6.00" Take Up
Couldn't load pickup availability
Turnbuckle – Midget, Hook and Hook, Malleable, #26 3/8 - 16
Couldn't load pickup availability
Product Description
• Turnbuckles can be used to apply tension to wire rope or cable• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class D
• Apply load to the center of end attachment eyes – do not side load eyes
CAUTION: Do not exceed working load limits.
Technical Specifications
| Item#: | 1442213 |
|---|---|
| Type | Eye and Eye |
| Diameter | 7/8 " |
| Closed Length | 22-1/2 " |
| Working Load Limit | 7,200 lb |
| Material | Forged Steel |
| Finish | Galvanized |
| UNSPSC #: | 24101611 |
| TAA Compliant: | Yes |
