Brass Ball Valve Forged Body with T-Handle 3/4x 3/4
(Pack of
1)
SKU:27147 Item#: 27147
• 24-hour 100% seal test guaranteed
• Full port for maximum flow
• Quarter-turn handle
• Blowout-proof nickel-plated brass stem
• Teflon® seats and adjustable packing gland
• Two-way flow for easier installation
• Chrome-plated brass ball for longer life
• Solder end female connections
• Working pressure: 600 PSI water, oil and gas• Meets UL Specification 842 – Valves for Flammable Fluids• Temperature range: –4°F to +350°F (–20°C to +177°C)
Frequently Bought Together
Rear Bumper Cover Retainer Plastic 18mm
Item#: P23263
$0.00
Couldn't load pickup availability
Bumper and Wheel Well Liner Push-Type Retainer
Item#: 1404768
$0.00
Couldn't load pickup availability
Fender Apron Drive Rivet 8mm Hole
Item#: 1365427
$0.00
Couldn't load pickup availability
Product Description
• 24-hour 100% seal test guaranteed• Full port for maximum flow
• Quarter-turn handle
• Blowout-proof nickel-plated brass stem
• Teflon® seats and adjustable packing gland
• Two-way flow for easier installation
• Chrome-plated brass ball for longer life
• Solder end female connections
• Working pressure: 600 PSI water, oil and gas• Meets UL Specification 842 – Valves for Flammable Fluids• Temperature range: –4°F to +350°F (–20°C to +177°C)
Technical Specifications
| Item#: | 27147 |
|---|---|
| Fitting Type | Ball Valve |
| Configuration | Forged Body with T-Handle |
| Material | Brass |
| Connection Type A x B | Female Solder x Female Solder |
| Fitting Dimension A | 3/4 " |
| Fitting Dimension B | 3/4 " |
| Working Pressure | 600 WOG PSI |
| Temperature Range | -4 to 350 F |
| UNSPSC #: | 40170000 |
| TAA Compliant: | Yes |
| Weight: | 0.7 lb |
