Wing-Type Toggle Bolt Anchor, Mushroom, Steel, Zinc Finish, 5/8" Drill Size, 1/4-20 x 3"
(Pack of
50)
SKU:25149 Item#: 25149
Toggle Bolt Assemblies
• Better spring action and more thread engagement
1. Insert bolt through item to be fastened, thread on wings, then fold wings completely back and insert through hole until wings spring open.
2. Pull back on assembly to hold wings against inside wall – this prevents the wings from spinning while tightening bolt. Tighten bolt firmly with screwdriver.
Frequently Bought Together
Toggle Bolt Anchor Assortment 70Pcs
$0.00
Couldn't load pickup availability
Conical Screw Anchor Kit Plastic 301Pcs
$0.00
Couldn't load pickup availability
Conical Screw Anchor Kit Plastic 401Pcs
$0.00
Couldn't load pickup availability
Open End Rivet Dome Head Aluminum 3/16"
$0.00
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M6-1 x 16mm
$0.00
Couldn't load pickup availability
Serrated Hex Flange Nut Alloy Steel M6-1
$0.00
Couldn't load pickup availability
Push-Type Retainer Nylon 16 x 19mm
$0.00
Couldn't load pickup availability
Bumper Fascia General Purpose Split Rivet 3/16"
$0.00
Couldn't load pickup availability
Fender Splash Shield Push Rivet Nylon 7mm Hole
$0.00
Couldn't load pickup availability
Pin Drive Anchor Mushroom Head Nylon 1/4 x 1"
$0.00
Couldn't load pickup availability
Toggle Bolt Anchor Wing 3/8-16
$0.00
Couldn't load pickup availability
Wing-Type Toggle Bolt Anchor Steel 1/4-20 x 4"
$0.00
Couldn't load pickup availability
Product Description
Toggle Bolt Assemblies• Better spring action and more thread engagement
1. Insert bolt through item to be fastened, thread on wings, then fold wings completely back and insert through hole until wings spring open.
2. Pull back on assembly to hold wings against inside wall – this prevents the wings from spinning while tightening bolt. Tighten bolt firmly with screwdriver.
Technical Specifications
| Item#: | 25149 |
|---|---|
| Length | 3 " |
| Type | Wall Anchor |
| Size | 1/4X3 " |
| Diameter | 1/4 " |
| Material | Steel |
| Head Style | Mushroom |
| Finish | Zinc |
| Thread | Coarse |
| Thread Pitch | 20 |
| Drill Size | 5/8 " |
| Anchor Size | 1/4 x 3 " |
| Tensile Proof Test Load In Concrete | 600 lb |
| Shear Proof Test Load | 600 lb |
| Bolt Size | 1/4-20 x 3 " |
| UNSPSC #: | 31162103 |
| TAA Compliant: | No |
| Weight: | 2.93 lb |
