Pilotdrive Cryotap M5 x 0.8 Starter Hand Tap
(Pack of
1)
SKU:DY80636012 Item#: DY80636012
• Easiest Starting Tap - CENTERLine™ point firmly lodges in the hole to eliminate tap shifting or wobbling with no guide blocks needed
• Non-Drifting - CENTERLine™ point maintains alignment from start to finish even while hand tapping
• Cryophase™ Treated - Increases tool life and maximizes torsion strength
• Precise - Perfect for tapping thin metals because the first few tapped threads are as clean and precise as the last few tapped threads
Specifications
• Material: High Speed Steel
• Coating: Gold Oxide
• Hardness: 64-66Rc
• Number of Chamfered Threads: 4 to 4-1/2 Threads
• Cryophase™: Thermal cycle cryogenic treatment
• Thread Standard: Exceeds ANSI B1.1
Note: Not intended for depths greater than 1-1/2 times tap diameter.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer -
www.P65Warnings.ca.gov
Frequently Bought Together
Abrasive Bristle Wire Belt Steel 23mm
$0.00
Couldn't load pickup availability
Cryoslash 3-5/8" x 1/2" x 0.025" Air Saw Blade 24 TPI
$0.00
Couldn't load pickup availability
Polymer Wheel Rubber Eraser 30mm
$0.00
Couldn't load pickup availability
SAE Interchangeable Nut Driver Set 11Pc
$0.00
Couldn't load pickup availability
4Pc Adjustable/Pipe Wrench Set
$0.00
Couldn't load pickup availability
DTM High Build Seam Sealer White 10fl.oz
$0.00
Couldn't load pickup availability
Front Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Front Bumper Drive Rivet Plastic 7mm Hole
$0.00
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
HSS Spiral Point Hand Tap M6 x 1
$0.00
Couldn't load pickup availability
HSS Spiral Point Hand Tap 5-40
$0.00
Couldn't load pickup availability
Pilotdrive Cryotap M18 x 1.5 Starter Hand Tap
$0.00
Couldn't load pickup availability
4-Flute HSS Bottoming Hand Tap M14 x 2
$0.00
Couldn't load pickup availability
4-Flute HSS Bottoming Hand Tap M4 x 0.7
$0.00
Couldn't load pickup availability
Carbon Steel Replacement Hand Tap M12 x 1.75
$0.00
Couldn't load pickup availability
Universal Socket Set, 3/8" Drive, 20pc
$0.00
Couldn't load pickup availability
8Pc Metric Mini Double Head Wrench Set
$0.00
Couldn't load pickup availability
Jobber Length Drill Bit HSS 6.5mm
$0.00
Couldn't load pickup availability
Product Description
• Easiest Starting Tap - CENTERLine™ point firmly lodges in the hole to eliminate tap shifting or wobbling with no guide blocks needed• Non-Drifting - CENTERLine™ point maintains alignment from start to finish even while hand tapping
• Cryophase™ Treated - Increases tool life and maximizes torsion strength
• Precise - Perfect for tapping thin metals because the first few tapped threads are as clean and precise as the last few tapped threads
Specifications
• Material: High Speed Steel
• Coating: Gold Oxide
• Hardness: 64-66Rc
• Number of Chamfered Threads: 4 to 4-1/2 Threads
• Cryophase™: Thermal cycle cryogenic treatment
• Thread Standard: Exceeds ANSI B1.1
Note: Not intended for depths greater than 1-1/2 times tap diameter.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Technical Specifications
| Item#: | DY80636012 |
|---|---|
| Type | Metric |
| Diameter | M5 |
| Pitch | 0.8 mm |
| Flutes | 4 |
| Overall Length | 2-3/8 " |
| Recommended Drill Size | 4.2 mm |
| UNSPSC #: | 23241615 |
| TAA Compliant: | No |
| Weight: | 0.02 lb |
