170 For Overlays And Build Up Wont Spall Or Mushroom Torchable Polarity Dc Or Ac Hardness 50Rc Tensile 125000 Unlimited Passes
(Pack of
5)
SKU:EG1702100B Item#: EG1702100B
Designed to provide sound weldments and overlays free of underbead cracks, which is essential for heavy buildup deposits on high-carbon and abrasion-resistant steels.
• All-Position – Allows build-up any position
• Torch Cuttable – Makes repairs easy
• High Deposition – Fast and economical
• Chrome-Moly Deposit – High-strength, high impact-resistance, heat-treatable
• Machinable
• Tensile Strength: 118,000 PSI/814 Mpa
• Yield Strength: 13,000 PSI/779 Mpa
• Hardness: 24 Rc
• Machinability: Good (carbide tools)
• Max Number of Passes: Unlimited
• Current: DC or AC
Remove fatigued metal. Preheat according to base metal type. Build up to desired dimensions using minimal amperage and heat input. Maintain short arc gap and allow to slow cool.
Frequently Bought Together
706 Hard Facing Buildup Stick Rod Electrode 5/32"
$0.00
Couldn't load pickup availability
706 Hard Facing Buildup Stick Rod Electrode 3/16"
$0.00
Couldn't load pickup availability
777 Austenitic Hard Facing Stick Electrode 5/32"
$0.00
Couldn't load pickup availability
676 Flux Core Wire Extreme Abrasion Moderate Impact .045X33LBS
$0.00
Couldn't load pickup availability
750 Martensitic Stick Rod Electrode 5/32"
$0.00
Couldn't load pickup availability
Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Bumper Cover Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Shield Push-Type Retainer with Metal Insert
$0.00
Couldn't load pickup availability
AWS E71T-11 Carbon Steel MIG Flux Core Welding Wire .035" 2lb
$0.00
Couldn't load pickup availability
Flint For Spring Loaded Trigger Torch Lighter
$0.00
Couldn't load pickup availability
Cronatron Welding Guide
$0.00
Couldn't load pickup availability
Product Description
Designed to provide sound weldments and overlays free of underbead cracks, which is essential for heavy buildup deposits on high-carbon and abrasion-resistant steels.• All-Position – Allows build-up any position
• Torch Cuttable – Makes repairs easy
• High Deposition – Fast and economical
• Chrome-Moly Deposit – High-strength, high impact-resistance, heat-treatable
• Machinable
• Tensile Strength: 118,000 PSI/814 Mpa
• Yield Strength: 13,000 PSI/779 Mpa
• Hardness: 24 Rc
• Machinability: Good (carbide tools)
• Max Number of Passes: Unlimited
• Current: DC or AC
Remove fatigued metal. Preheat according to base metal type. Build up to desired dimensions using minimal amperage and heat input. Maintain short arc gap and allow to slow cool.
Technical Specifications
| Item#: | EG1702100B |
|---|---|
| Welding Process | Stick |
| Type | Electrode |
| Diameter | 5/32 " |
| Base Metal | Carbon And Alloy Steels |
| Hardness | 55 HRC |
| UNSPSC #: | 23271810 |
| TAA Compliant: | Yes |
| Weight: | 5.44 lb |
