HuckBolt® Magna-Grip® Rivet Lockbolt, Round/Button Head, Carbon Steel, Zinc Plated, 3/8" Diameter, 0.125 to 0.875" Grip Range
(Pack of
10)
Delivering uniform, consistent clamp load and high shear and tensile strength, HuckBolts® are ideal for applications ranging from general manufacturing to high-vibration environments such as HVAC, trailer and container assembly and repair, rotating equipment, railroad and transit cars, storage pods, and many others.
HuckBolts® feature an exclusive locking groove design that ensures a tight, permanent fit. In addition to superior fastening performance regardless of which lock bolt type you require, HuckBolts® have been proven to reduce labor and installation costs, along with rework and warranty expenses.
• Offers the highest level of vibration resistance available
• Consistently provides high, uniform installed values
• Wide grip range can replace up to four traditional HuckBolts®
• Flush-breaking, lock-groove design provides a wide grip range to reduce inventory requirements
• Easy, consistently accurate installations minimize operator errors and rework costs
• Collar material swaged into the annular pin grooves forms a permanent, vibration-proof connection
• Round/button head design
• Zinc-plated carbon steel
Frequently Bought Together
Serrated Hex Flange Nut Alloy Steel M6-1
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M6-1 x 12mm
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M10-1.25 x 30mm
Couldn't load pickup availability
HuckBolt® C50L® Rivet Lockbolt Button Head 5/8"
Couldn't load pickup availability
Multi-Grip Lockbolt Rivet Head Steel 3/16"
Couldn't load pickup availability
Multi-Grip Lockbolt Button Head Carbon Steel 1/4"
Couldn't load pickup availability
Open End Rivet Dome Head Aluminum 5/32"
Couldn't load pickup availability
Open End Rivet Large Flange Head Aluminum 3/16"
Couldn't load pickup availability
Open End Rivet Dome Head Aluminum 1/8"
Couldn't load pickup availability
Fender Apron Drive Rivet 8mm Hole
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Fender Bumper Shield Retainer 11/16"
Couldn't load pickup availability
Product Description
Delivering uniform, consistent clamp load and high shear and tensile strength, HuckBolts® are ideal for applications ranging from general manufacturing to high-vibration environments such as HVAC, trailer and container assembly and repair, rotating equipment, railroad and transit cars, storage pods, and many others.HuckBolts® feature an exclusive locking groove design that ensures a tight, permanent fit. In addition to superior fastening performance regardless of which lock bolt type you require, HuckBolts® have been proven to reduce labor and installation costs, along with rework and warranty expenses.
• Offers the highest level of vibration resistance available
• Consistently provides high, uniform installed values
• Wide grip range can replace up to four traditional HuckBolts®
• Flush-breaking, lock-groove design provides a wide grip range to reduce inventory requirements
• Easy, consistently accurate installations minimize operator errors and rework costs
• Collar material swaged into the annular pin grooves forms a permanent, vibration-proof connection
• Round/button head design
• Zinc-plated carbon steel
Technical Specifications
| Item#: | 1504953 |
|---|---|
| Series | Multi-Grip |
| Diameter | 3/8 " |
| Maximum Hole Size | 0.422 " |
| Grip Range | 0.125 - 0.875 " |
| Head Style | Button (Brazier) Head |
| Length | 2.865 - 2.965 " |
| Material | Carbon Steel |
| Finish | Zinc Plated |
| Head Diameter | 0.720 - 0.780 " |
| Head Height | 0.220 - 0.250 " |
| Clamp Load | 4,000 lb |
| Tensile Strength | 9,000 lb |
| Shear Strength | 6,000 lb |
| UNSPSC #: | 31162201 |
| TAA Compliant: | No |
| Weight: | 0.95 lb |
