SNAPTOGGLE® Toggle Bolt Anchor, 1/2" Drill Size, 1/4-20
(Pack of
25)
• Three times faster than conventional toggle bolts
• Requires a smaller pilot hole and uses a shorter bolt
• Stays in place with or without a bolt
• Heads won’t fall behind wall
• Wall or ceiling thickness range: 3/8" – 2-1/2"
• Minimum bolt length: Fixture thickness + wall or ceiling thickness + 1/2"
• Minimum clearance behind wall: 1-7/8"
Tests are ultimate load. However, industry safety standards recommend 1/4 of the value for actual application. Age and condition of the material and the screw size will cause tensile strength to vary.Toggler® is a registered trademark of Mechanical Plastics Corp.
Frequently Bought Together
Masonry Anchor Hex Washer Head Steel 1/4 x 1"
Couldn't load pickup availability
Masonry Anchor TORX® Star Head Steel 1/4 x 1-3/4"
Couldn't load pickup availability
Sleeve Type Stud Bolt Anchor Steel 5/16 x 3-1/2"
Couldn't load pickup availability
Open End Rivet Dome Head Aluminum 5/32"
Couldn't load pickup availability
Serrated Hex Flange Nut Alloy Steel M8-1.25
Couldn't load pickup availability
Self-Drilling Screw Hex Head #8-18 x 1/2"
Couldn't load pickup availability
Shroud Insulating Button Nylon 11/16"
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
Couldn't load pickup availability
Fender Splash Shield Retainer Nylon 20mm
Couldn't load pickup availability
Tubular Anchor Plastic White #4 to #6
Couldn't load pickup availability
SNAPTOGGLE® Toggle Bolt Anchor 3/16-24
Couldn't load pickup availability
E-Z Toggle™ Self-Drilling Wall Anchor
Couldn't load pickup availability
Product Description
• Three times faster than conventional toggle bolts• Requires a smaller pilot hole and uses a shorter bolt
• Stays in place with or without a bolt
• Heads won’t fall behind wall
• Wall or ceiling thickness range: 3/8" – 2-1/2"
• Minimum bolt length: Fixture thickness + wall or ceiling thickness + 1/2"
• Minimum clearance behind wall: 1-7/8"
Tests are ultimate load. However, industry safety standards recommend 1/4 of the value for actual application. Age and condition of the material and the screw size will cause tensile strength to vary.Toggler® is a registered trademark of Mechanical Plastics Corp.
Technical Specifications
| Item#: | 90918 |
|---|---|
| Type | Toggle Bolt Anchor |
| Size | 1/4-20 " |
| Diameter | 1/4 " |
| Thread | Coarse |
| Thread Pitch | 20 tpi |
| Drill Size | 1/2 " |
| Tensile Proof Test Load In Concrete | 925 lb |
| Shear Proof Test Load | 1,477 lb |
| Tensile Proof Test Load | 877 lb |
| Bolt Size | 1/4-20 " |
| UNSPSC #: | 31162103 |
| TAA Compliant: | Yes |
| Weight: | 0.86 lb |
