889 Cast Iron Stick Rod Electrode, Flux Coated, 180 to 222 HB Hardness, 60 to 100 Amps, DCRP/DCSP/AC Polarity, 3/32"
(Pack of 10)

SKU:P12001 Item#: P12001

Certanium®

All-position welding for any type of weldable cast iron repair and cast iron to steel.
Superior Advantages
• High strength welds
• Fully machinable
• Pass-over-pass welding to save time
• All-position welding may eliminate the need to dismantle equipment to perform repairs
For all cast irons – even steel to cast iron
Tensile Strength: Up to 84,000 PSIHardness: 180 – 222 BHNPolarity: AC or DC Straight or Reverse
Typical Applications
• Pump and bearing housings
• Cylinder blocks and heads
• Machine bases
• Manifolds and exhaust systems
Usage Procedure:Remove grease, scale and other impurities from weld area. Bevel cracks or breaks (70° to 90° “V”). CRONACUT™ 1100 is the fastest and easiest method to prepare section for weld repairing. Use a short to medium arc at the lowest possible amperage for best results. Employ weaving technique or stringer beads. Peen to relieve stress. Remove slag between passes. Slow cooling to room temperature recommended.

Check Availability

Quantity

Frequently Bought Together

270 Cast Iron Stick Rod Electrode 3/16"

889 Cast Iron Stick Rod Electrode 5/32"

222 Cast Iron Stick Rod Electrode 1/8"

Front Bumper and Radiator Support Drive Rivet

Front Bumper Drive Rivet Plastic 10mm Hole

Miniature Incandescent Bulb 12V 2CP

Light Weight Composite Wear Plates 36X4X13/64

Item#: EG09910436

Acetylene Safety Cap Heavy Duty

Round Soapstone Holder Heavy Duty

360 Mild and Carbon Steel Stick Rod Electrode 1/8"

1100 Gouging and Cutting Stick Rod Electrode 1/4"

889 Cast Iron Stick Rod Electrode 3/16"

Product Description

All-position welding for any type of weldable cast iron repair and cast iron to steel.
Superior Advantages
• High strength welds
• Fully machinable
• Pass-over-pass welding to save time
• All-position welding may eliminate the need to dismantle equipment to perform repairs
For all cast irons – even steel to cast iron
Tensile Strength: Up to 84,000 PSIHardness: 180 – 222 BHNPolarity: AC or DC Straight or Reverse
Typical Applications
• Pump and bearing housings
• Cylinder blocks and heads
• Machine bases
• Manifolds and exhaust systems
Usage Procedure:Remove grease, scale and other impurities from weld area. Bevel cracks or breaks (70° to 90° “V”). CRONACUT™ 1100 is the fastest and easiest method to prepare section for weld repairing. Use a short to medium arc at the lowest possible amperage for best results. Employ weaving technique or stringer beads. Peen to relieve stress. Remove slag between passes. Slow cooling to room temperature recommended.

Technical Specifications

Item#:	P12001
Welding Process	Stick
Type	Flux Coated
Diameter	3/32 "
Tensile Strength	84,000 PSI
Base Metal	Cast Iron
Hardness	180-222 BHN
Polarity	DCRP/DCSP/AC
Ford Tox Number	019982
UNSPSC #:	23271810
TAA Compliant:	Yes
Weight:	10.0 lb
